Avoiding Common Pitfalls in Solenoid Valve Installation for a Flawless Irrigation System
Avoiding mistakes in the installation of electrical valves and preventive measures
March 28, 2025
Getting your irrigation system up and running comes with its challenges, especially when it comes to solenoid valves. Even professionals can trip up, but that's where we come in. Here's a breakdown of the most frequent pitfalls in solenoid valve installation and some handy tips to steer clear of them.
1. Picking the Wrong Solenoid Voltage
The solenoid is what dictates whether a valve operates at 9 Vcc or 24 Vca, not the valve body itself. To distinguish them, observe the colors of the cables:
- 9 V CC Solenoid: different-colored cables.
- 24 V CA Solenoid: both cables black.
To ensure your valve runs smoothly, simply swap out the solenoid to match the required voltage when necessary. Keep in mind that this is only possible between valves of the same brand or while using one of our handy adapters.
2. Incompatible Control Unit and Valve
Make sure your valve voltage matches that of the control unit. Installing a 24 VCA valve into a 9 VCC control unit system, like our Pure Vision well control unit, won't yield the desired results.
3. Mounting Solenoid Valves in Reverse
Installing the solenoid valve in reverse can cause issues and reduce the irrigation system's efficiency. To dodge this mishap, look for an arrow printed on the valve body indicating the direction of water flow.
4. Skipping Filter Installation
Solenoid valves are susceptible to problems caused by debris, so skipping a filter upstream can lead to clogging, blocking, and damage. Be kind to your valve and install a filter to keep it clean and functioning optimally.
5. Incorrect Electrical Connection
A incorrect connection can cause short circuits or prevent the valve from opening and closing. Ensure you connect the solenoid cables to the appropriate terminals of the control unit as instructed by the manufacturer.
Now, if you're looking for top-notch solenoid valves featuring our patented Manifold system, look no further! Our valves equipped with a rotating nut will speed up installation and maintenance, putting greater efficiency and ease-of-use at your fingertips.
To nail the installation of your solenoid valves and guarantee the long life of your irrigation system, always bear these guidelines in mind. By heeding them, you'll dodge common mistakes and ensure superior performance from your irrigation system.
