Constructing a 3D-Printed Radio Controlled Dump Truck
Step aside from your daily grind, because it's time to take the helm of a colossal dump truck, thanks to this mind-blowing 3D-printed creationby the legend that is ProfessorBoots!
This mind-boggling DIY project comprises two main components: the beefy tractor and the mighty trailer, commanded by a remote control. The tractor resembles a real-life Big-Rig, boasting six wheels and a sophisticated retractable magnetic hitch mechanism. It's capable of coupling up with various trailers and detaching them as required, with a simple press of a button on the remote. The hitch offers provisions for power and control lines that regulate the attached trailer's movements.
As for the trailer, it's an impressive side-dumper that can fling its cargo to the left or right according to your whim. The dumping action is controlled via a linear actuator powered by a small DC motor and a threaded rod. A servo manages a sliding locking mechanism, which decides whether the mighty truck dumps its contents to the left or right, as the linear actuator lifts the bed to unload materials.
The design video showcases the 3D-printed blueprint, along with thrilling footage of the dump truck in action. ProfessorBoots' innovations have previously impressed us, like this amazing 3D-printed forklift. Check out the video below to see the dump truck in action!
The 3D-printed dump truck by ProfessorBoots incorporates:
- A tractor and body made primarily from 3D-printed parts, with realistic proportions resembling mining haulers.
- Simple N20 motors driving the truck, with gear reductions attached to the rear axles.
- Leaf springs for suspension and load handling at the front.
- A servo-controlled sliding locking mechanism to direct the dumping action.
- A linear actuator to raise the dump bed for unloading.
- Step-by-step instructions for building the dump truck available online.
- Similar projects, such as a 3D-printed forklift with the same combination of 3D-printed parts and standard RC components for realistic operation.
These designs prove that 3D printing and affordable electronics can collaborate to manufacture lifelike, functional scale models of industrial vehicles, right at your desk!
This DIY project by ProfessorBoots, consisting of a 3D-printed tractor and dump trailer, is operated by a remote control and features a retractable magnetic hitch mechanism, reminiscent of real-life Big-Rigs. The trailer, an impressive side-dumper, is equipped with a linear actuator and servo that control the dumping action and sliding locking mechanism, respectively.
The novelties by ProfessorBoots, such as the 3D-printed dump truck and forklift, demonstrate the potential of 3D printing and affordable electronics to create lifelike, functional scale models of industrial vehicles, right at your desk, and are a testament to the fusion of DIY gadgets and technology.
