Driving in California Could Potentially Power the Grid via Harnessed Vibrations
Road Traffic Piezoelectric Energy Harvesting: A Promising Renewable Energy Source
California is exploring a novel and innovative approach to renewable energy generation – vibrational energy from road traffic. This technology, known as piezoelectric generation, involves placing sensors under the road surface to collect vibrations caused by passing vehicles and convert them into electrical power.
The potential impact of this technology is impressive. For heavy trucks, the annual electric energy generation over one mile of a one-lane highway could be as high as 907,873 kilowatt-hours. A one-mile stretch of a two-lane highway could potentially generate enough electricity to power approximately 500 homes for an entire year or charge 120 electric vehicles daily.
The California Energy Commission has allocated $2.3 million towards testing the viability of generating electrical power from traffic vibrations. A pilot program is being conducted by Pyro-E, a green tech company based in San Jose.
Piezoelectric energy harvesting is moderately effective for generating renewable energy, typically producing on the order of several milliwatts per harvester device. However, when deployed at scale along heavily trafficked roadways, the potential for meaningful cumulative energy generation is significant. For example, a 1-kilometer stretch of highway embedded with piezoelectric materials under heavy traffic is estimated to generate up to about 44 MWh per year, which can sufficiently power small local loads.
The efficiency and power output depend strongly on factors like harvester design, traffic load (vehicle weight, frequency, axle load), and the interaction with the underlying structure (road or bridge). Advanced designs, such as stacked piezoelectric transducers and triboelectric nanogenerators embedded in the roadbed, have achieved peak powers around 16 milliwatts from small areas under single tire impacts with efficiencies around 11%.
Beyond roadways, piezoelectric energy harvesting has promising applications in bridge and railway monitoring, smart transportation systems, energy recovery from braking systems, and self-powered Internet of Things (IoT) sensors. This energy generation is equivalent to reducing 300 metric tons of carbon dioxide emissions, making it a viable renewable energy source for low-power applications, especially sensor networks and smart infrastructure.
In summary, piezoelectric energy harvesting from road traffic is a promising renewable energy source for low-power applications, especially sensor networks and smart infrastructure, with expanding potential beyond roadways into bridges, railways, and kinetic energy recovery systems. Its effectiveness is context-dependent but promising with advancing technology and integration strategies.
