Guide on Choosing the Right Pump Size for an Aquarium's Return Flow
In the vibrant world of saltwater aquariums, maintaining optimal water flow is crucial for the health of your marine inhabitants, particularly corals. Here's a comprehensive guide to help you select the appropriate return pump for your tank.
Step 1: Determine the Required Flow Rate
The first step is to establish the required flow rate for your saltwater aquarium. A general rule of thumb is that the flow rate should be around 10 to 20 times the tank volume per hour. This ensures adequate water circulation and oxygenation.
- Formula: Flow Rate (GPH) = Tank Volume (Gallons) x 10 to 20
- Example: For a 100-gallon tank, the flow rate could be 1000 to 2000 GPH.
Step 2: Calculate Head Pressure
Head pressure, the resistance the pump must overcome to push water back into the tank, is influenced by factors like the height of the pump outlet above the water surface, fittings, and any obstacles in the plumbing.
- Measure the vertical distance from the pump outlet to the top of the tank. Typically, a 1-foot increase in height corresponds to a 0.433 psi increase in pressure. Other fittings and bends can add another 0.5 to 1 psi.
Step 3: Choose the Right Pump
Select a return pump that can deliver the calculated flow rate at the determined head pressure. Manufacturers often provide flow charts or tables that show the pump's performance at different head pressures.
- Guideline: Select a pump with a flow rate slightly above the minimum required to account for any losses due to fittings and pipe resistance.
Step 4: Consider Additional Factors
Other factors to consider include the pump's efficiency, noise level, and power consumption. A more efficient pump uses less power while delivering the same flow rate.
Step 5: Finalize the Pump Selection
Once you have calculated the required flow rate and head pressure, compare these values with the specifications of available pumps. Choose a pump that meets or exceeds these requirements.
Remember, every 10 ft of flat horizontal distance in the plumbing equals 1 ft of head pressure, every 45° elbow fitting equals 0.5 ft of head pressure, and every 90° elbow fitting equals 1 ft of head pressure.
By following these steps, you can identify the appropriate return pump size for your saltwater aquarium. Always use your tank's total water volume to estimate how many times per hour the return pump can cycle your entire water volume through the filtration system. Anywhere from 2x - 10x total tank turnover per hour is generally acceptable.
For reef aquariums, the general rule among hobbyists is to find a pump that can deliver at least 5x to 10x the tank's total water volume per hour. For example, for a 50-gallon tank, look for a pump rated at least 250-500 GPH.
In the case of a sump located below the tank, the return pump moves water from the sump back up into the aquarium. In an All-In-One style tank, the return pump moves water through the back filtration chambers and into the display. The return pump creates a constant, circular flow of water through the display aquarium and filtration system, often referred to as "the heart" of the aquarium.
It's important to choose a slightly more powerful return pump rather than a questionably undersized one. DC-powered controllable pumps come with electronic controllers that allow you to change the pump speed and resulting flow rate, giving you control over your aquarium's water flow. AC pumps should always be plumbed using an in-line valve with a true union connection between the pump and the tank.
Using a pump manufacturer's flow chart can help determine the true pump flow rate based on the head pressure created. Using a pump that is too small can lead to insufficient water flow, causing poor oxygenation, waste build-up, and potentially harming your marine life. On the other hand, a pump that is too large can result in unnecessary energy consumption and noise.
By carefully considering the factors outlined in this guide, you can make an informed decision when choosing a return pump for your saltwater aquarium, ensuring a thriving and healthy underwater environment for your marine life.
