Supports Dependable Disconnections in Electric Vehicles, Charging Stations, and Energy Storage Units: DC Contactors
TDK's HVC50 high-voltage DC contactor is a versatile and efficient solution designed for safe and reliable operation in various applications, including energy storage systems (ESS), megawatt charging systems (MCS), and vehicle-to-grid (V2G) scenarios.
Key Features
The HVC50 boasts several key features that make it an ideal choice for high-voltage applications:
- Current and Voltage Ratings: The HVC50 is rated for continuous currents of up to 750 A and can handle surges of up to 1,000 A. It supports DC voltages of up to 1,500 V[1].
- Disconnect Time: It can disconnect currents in less than 30 ms, ensuring rapid disconnection under emergency conditions[1].
- Arc Chamber Technology: Equipped with a gas-ceramic arc chamber, which enhances safety by ensuring effective current disconnection even in extreme conditions[1].
- Mirror Contact: Features an integrated mirror contact that provides precise switching feedback, enhancing operational safety and meeting IEC 60947-4-1 standards[1].
- Bidirectional Capability: Supports both V2G and power banking due to its bidirectional design[1].
- Operating Efficiency: Uses a dual-coil design for operating voltages of 12 or 24 V. The making power is 50 W, while the steady-state power is only 6 W after one of the coils is switched off after about 200 ms[1].
- Compact Design: Weighs 1.7 kg and measures 97.8 × 140 × 94.2 mm, making it easy to integrate into various applications[1].
Applications
The HVC50 is ideally suited for the following applications:
- Energy Storage Systems (ESS): The HVC50 is used in ESS to manage the flow of electrical energy, ensuring safe and efficient operation[1].
- Megawatt Charging Systems (MCS): It supports high-power charging systems designed for rapid charging of electric vehicles[1].
- Vehicle-to-Grid (V2G) Applications: Enables vehicles to supply power back to the grid when needed, enhancing grid stability and efficiency[1].
In conclusion, the HVC50 is a reliable and efficient high-voltage DC contactor designed to provide safe and efficient switching in high-voltage applications, ensuring safety and performance across different energy systems.
For more detailed information about the HVC50, please visit the provided link.
[1] TDK Corporation. (n.d.). HVC50 High-voltage DC contactor. Retrieved from https://www.tdk.com/info/en/product/hvc50/
- The HVC50's bidirectional capability, combined with its smooth integration in various applications, makes it a suitable choice for both science and technology sectors, specifically in managing electrical energy flow in energy storage systems and power banking.
- The innovative arc chamber technology of the HVC50 not only enhances safety in extreme conditions but also aligns with advancements in science and technology, contributing to the development of safe and efficient technology solutions such as megawatt charging systems and vehicle-to-grid applications.
